Otsuka OLED Inspection Lighting – EL270F

Product features

The MODELIGHT series was developed as lighting for visual inspection aimed at reducing eye fatigue that burdens workers. At inspection sites, inspection is often conducted using a room lighting or fluorescent lighting for work, but there are cases in which this is a burden to the worker, such as when it is impossible to secure a proper level of brightness or when it is too bright. This product is optimal for improving this situation and conducting inspections with proper lighting. It uses a robust free arm made of stainless steel, making this product able to withstand hard use at manufacturing sites. Performance is improved by equipping it with an optional auxiliary lens, which can function as a magnifying glass.

Next generation inspection illumination: Equipped with the latest OLED panel, brightness is increased by 300% (compared to the previous model MODELIGHT).

Technical Specification

Technical Specification



Product Name : OLED inspection lighting

Model Name : EL270F(table clamp type)

Lens
Illumination
Light source OLED lighting panel
Input rated input voltage 100~240V・50/60Hz・A plug
※it can be used from 125 to 240V,By changing the cord with AC plug.
Rated power consumption 13W
Dimming function Yes(100%〜10%)
Illuminance directly under the center (Max) 2170LX/150mm 710LX/300mm 290LX/500mm  (measured by our measurement method)
Illuminance directly under the center (Min)  160LX/150mm 50LX/300mm 20LX/500mm  (measured by our measurement method)
Color temperature 4000K( white )
Average color rendering index (Ra) 90
Luminous surface size (mm) L273×W30
Total luminous flux (lm) 200 (パネル1枚あたり)
AC adapter model, rating UNIFIVE336-2415(24V/1.5) weigh:270g
Body
Weight(Kg) 2.6 (Main body weight))
Dustproof/waterproof protection class P20 (for indoor use only)
Clampable width (mm) 10-60 (board thickness)
